304 316L Stainless Steel Capillary Tubing Outer Diameter 0.3---25mm Wall Thickness 0.1

Brand Name : yue lin sen

Model Number : Y05

Certification : ISO9001 ISO13485

Place of Origin : Dongguan City, Guangdong Province

MOQ : 100 pcs

Price : 0.5-20

Payment Terms : T/T

Supply Ability : 50000 pcs One month

Delivery Time : 5-8wofk days

Packaging Details : Vacuum packaging; cardboard box; wooden box; packaging customized according to product specifications

Finishing : Polish, HL, MF, Matte, Satin, et

Od Tolerance : +/-0.15mm

Pressure Resistance : High

Outer Diameter : 0.3mm-10mm

Industry : medical industry

Corrosion Resistance : High

Application : Medical, industrial, and scientific purposes

Temperature Resistance : High

Technique : Cold Drawn

Processing Service : Cutting, Bending, Welding, Punching

Production Standard : GB ISO13485 ISO9001

Sample : Provide

Shape : Round

Material : Stainless steel

Contact Now

304 316L Stainless Steel Capillary Tubing, Outer Diameter 0.3---25mm, Wall Thickness 0.1, Specifications, Custom Shapes

Product Description

Our precision capillaries are manufactured from premium 316L and 304 stainless steel, offering exceptional corrosion resistance and mechanical strength. With customizable outer diameters (0.3 mm to 25 mm) and wall thicknesses (0.1 mm to 3.0 mm), these tubes are engineered for demanding applications across diverse industries. The inclusion of molybdenum in 316L enhances performance in harsh environments, while 304 provides a cost-effective solution for general use. Custom shaping services ensure tailored solutions for specialized needs.

Technical Specifications
Category Details
Material 316L Stainless Steel, 304 Stainless Steel
Outer Diameter (OD) 0.3 mm to 25 mm (Customizable)
Wall Thickness 0.1 mm to 3.0 mm (Customizable)
Key Properties Corrosion Resistance, High Mechanical Strength, Flexibility
316L Advantages Molybdenum Addition, Superior Performance in Marine/Chemical Environments
304 Advantages Cost-Effective, Good Rust Resistance
Customization Custom Shapes, Sizes, and Tolerances
Applications
  • Medical Devices: Catheters, hypodermic needles, endoscopic tools, and fluid transfer systems.
  • Aerospace: Hydraulic lines, sensor conduits, and lightweight structural components.
  • Automotive Manufacturing: Fuel injection systems, brake lines, and precision tubing.
  • Precision Instruments: Chromatography columns, probe housings, and analytical equipment.
  • Industrial Use: Chemical processing, marine equipment, and high-purity fluid handling.
Key Advantages
  1. Material Versatility: Choose between 316L (extreme corrosion resistance) and 304 (economical reliability).
  2. Precision Sizing: Tight tolerances for outer diameter and wall thickness.
  3. Custom Shapes: Tailored geometries (e.g., coiled, tapered, or non-circular cross-sections).
  4. Durability: Suitable for high-pressure, high-temperature, and corrosive environments.
  5. Industry Compliance: Meets standards for medical (ISO 13485), aerospace (AS9100), and automotive (IATF 16949) applications.

Note: These capillaries are ideal for prototypes and mass production, with technical support available for design optimization. Samples can be provided for validation testing.
